1000 ICA6

The Focal 1000 ICA6 is a premium in-ceiling loudspeaker designed for discreet, high-performance stereo and home theater installations. Its angled coaxial design ensures precise sound placement, making it ideal for immersive Dolby Atmos® systems.

Built with Focal’s exclusive “W” cone and pure Beryllium tweeter, it delivers exceptional clarity, detail, and dynamic range. Adjustable settings and paintable magnetic grilles allow seamless integration into any space, while the Easy Quick Install system ensures fast, tool-free setup.

!
This product cannot be purchased online.
Please contact us for pricing and availability: (206) 462‑5227
Contact Us For Availability

The Focal 1000 ICA6 is a premium 2-way coaxial in-ceiling loudspeaker designed for discreet high-fidelity stereo and home theater installations. Part of Focal’s 1000 Series, it combines a 6.5-inch “W” cone midrange/bass driver with a pure Beryllium inverted-dome tweeter to deliver exceptionally detailed and transparent sound from a virtually invisible architectural installation.

Its innovative design features a 35° angled midrange/bass driver, allowing the speaker to be precisely directed toward the listening position. This makes the 1000 ICA6 particularly well suited to Dolby Atmos applications, where accurate positioning of overhead sound is essential for creating a convincing three-dimensional soundstage.

The pure Beryllium tweeter provides extended high-frequency response and exceptional microdetail, while its adjustable position and level allow the speaker to be fine-tuned according to the room and listening position. Focal’s “W” cone construction contributes to controlled bass and midrange reproduction with low distortion and high transparency.

Installation is designed to be fast and discreet thanks to Focal’s patented Easy Quick Install system. The 1000 ICA6 includes both square and circular magnetic grilles that can be painted to match the ceiling, allowing the speaker to blend seamlessly into residential interiors while providing the performance required for high-end music and immersive home theater systems.

  • Product type: 2-way coaxial in-ceiling loudspeaker

  • Midrange/bass driver: 6.5" (16.5 cm) “W” cone

  • Tweeter: 1" (25 mm) pure Beryllium inverted-dome tweeter

  • Driver orientation: 35° angled midrange/bass driver

  • Frequency response: 55 Hz – 44 kHz (±3 dB)

  • Low-frequency cutoff: 45 Hz (-6 dB)

  • Sensitivity: 90.5 dB

  • Nominal impedance: 8 ohms

  • Minimum impedance: 5.1 ohms

  • Recommended amplifier power: 25–150 W

  • Cutout diameter: 264 mm

  • Overall dimensions: 299 × 127 mm

  • Mounting depth: 146 mm

  • Weight: 3 kg with grille

  • Installation: Focal Easy Quick Install (EQI), no tools required

  • Grilles: Square and circular magnetic grilles, ready to paint

  • Included accessories: Black and white felt, cutout template

  • Application: Stereo, home theater, and Dolby Atmos installations
